BYD Pallet Mover P20PS | 2 ton
BYD Pallet Mover P20PS | 2 ton
Key Technical Specifications
Feature Specification;
Model P20PS.
Load Capacity 2,000 kg (2.0 Ton).
Load Center 600 mm.
Battery Type Lithium Iron-Phosphate (LiFePO4).
Battery Capacity 24V / 130Ah (Standard).
Travel Speed 6 km/h (Laden/Unladen).
Service Weight Approx. 700 kg (including battery).
Turning Radius 1,750 mm.
Lift Height 120 mm.
Fork Dimensions 60 x 180 x 1,220 mm (Standard).
Aisle Width 1,989 mm (for 800×1200 pallets).
Description
BYD Pallet Mover P20PS | 2 ton
The BYD P20PS is a high-performance, stand-on electric pallet mover (BOPT) with a 2-ton (2,000 kg) capacity.
It is primarily known for its Lithium Iron-Phosphate (LiFePO4) battery technology, which allows for rapid charging and a significantly longer lifespan compared to traditional lead-acid units.
Key Technical Specifications
Feature Specification;
Model P20PS.
Load Capacity 2,000 kg (2.0 Ton).
Load Center 600 mm.
Battery Type Lithium Iron-Phosphate (LiFePO4).
Battery Capacity 24V / 130Ah (Standard).
Travel Speed 6 km/h (Laden/Unladen).
Service Weight Approx. 700 kg (including battery).
Turning Radius 1,750 mm.
Lift Height 120 mm.
Fork Dimensions 60 x 180 x 1,220 mm (Standard).
Aisle Width 1,989 mm (for 800×1200 pallets).
Core Performance Features
Rapid Charging: Can be fully charged in approximately 1 to 2 hours (with optional quick charger).3 It supports “opportunity charging,” meaning you can plug it in during short breaks without damaging the battery.
Battery Longevity: The battery is designed for over 4,000 cycles, typically lasting more than 10 years under standard usage.
Operator Comfort: Features a stand-on platform with foldable side bars.6 The platform is often shock-absorbent and non-slip to reduce fatigue during long shifts.
Electric Power Steering: Provides effortless maneuverability, making it easier to navigate tight warehouse aisles.
Safety Systems:
Automatic Braking: Engages when the handle is released or in a vertical/horizontal position.
Speed Reduction: Automatically slows down when cornering to prevent tipping.
Overload Protection: Prevents lifting loads beyond the 2-ton capacity.
Maintenance & Durability
Maintenance-Free: Unlike lead-acid batteries, the BYD LiFePO4 battery requires no water topping or specialized charging rooms.
AC Drive System: Uses a brushless AC motor which reduces wear and tear and lowers long-term maintenance costs.
Tires: Standard polyurethane (PU) wheels, providing high durability and low rolling resistance on industrial floors.
Would you like me to compare these specs with the pedestrian version (P20JW) or help you find local pricing for this model?
