Caterpillar Mini Excavator 301-5 | 1.7 ton

Caterpillar Mini Excavator 301-5 | 1.7 ton
Net Power
15.7 kW
Operating Weight
1775 kg
Dig Depth
2540 mm

Description

Caterpillar Mini Excavator 301-5 | 1.7 ton

BELIALAT.COM support unit, parts, service, rental, maintenance contract, overhaul, reconditioned Caterpillar Mini Excavator 301-5 | 1.7 ton

Specification Unit Caterpillar Mini Excavator 301-5 | 1.7 ton

Engine

Net Power 15.7 kW
Engine Model C1.1
Displacement 1.1 l
Stroke 81 mm
Bore 77 mm
Emissions Meets U.S. EPA Tier 4 Final and EU Stage V emission standards.
Note Net power is tested per ISO 9249:2007 and 80/1269/EEC.

Note 1

Net power advertised is the power available at the flywheel when the engine is at rated speed and rated power when the engine is installed with the factory configured fan, air intake system, exhaust system, and alternator with a minimum alternator load.
Note 2

Engine power is tested per ISO 14396:2002.
Net Power – 2,400 rpm – ISO 9249, 80/1269/EEC 15.7 kW
Gross Power – SAE J1995:2014 16.1 kW

Weight

Operating Weight 1775 kg
Minimum Operating Weight with Canopy* 1580 kg
Note (1) *Minimum Weight is based on rubber tracks, operator, fixed undercarriage and full fuel tank.
Maximum Operating Weight with Canopy** 1775 kg
Note (2) **Maximum Weight is based on steel tracks, operator, expandable undercarriage and full fuel tank.
EU: CE Plate Weight*** 1740 kg
Note (3) ***CE Plate Weight is based on the most common EU configuration. Includes 75 kg (165 lb) operator and full fuel tank and excludes bucket.

Working Ranges and Forces

Maximum Digging Depth 6820 mm
Boom HD Reach 5.9 m (19’4″)
Stick HD Reach 2.95 m (9’8″).

Bucket HD 1.54m³ (2.01 yd³)
Maximum Reach at Ground Level 10120 mm.

Maximum Cutting Height 9640 mm
Maximum Loading Height 6620 mm.

Minimum Loading Height 2390 mm
Maximum Depth Cut for 2440 mm (8 ft) Level Bottom 6650 mm.

Maximum Vertical Wall Digging Depth 5110 mm
Bucket Digging Force – ISO 166 kN.

Stick Digging Force – ISO 121 kN

Hydraulic System

Pump Flow at 2,400 rpm 66 L/min
Digging Force – Stick – Long 7.2 kN
Operating Pressure – Swing 103 bar
Digging Force – Stick – Standard 8.2 kN
Auxiliary Circuit – Primary – Flow 33 L/min
Auxiliary Circuit – Secondary – Pressure 213 bar
Operating Pressure – Travel 213 bar
Operating Pressure – Equipment 213 bar
Auxiliary Circuit – Secondary – Flow 14 L/min
Digging Force – Bucket 14.1 kN
Auxiliary Circuit – Primary – Pressure 213 bar
Type Load Sensing Hydraulics with Variable Displacement Piston Pump

Swing Machine

Machine Swing Speed 9.8 r/min

Service Refill Capacities

Cooling System 3.9 l
Engine Oil 4.4 l
Hydraulic System 26 l
Hydraulic Tank 18 l
Fuel Tank 22 l

Dimensions

Dig Depth 2540 mm
Maximum Blade Height 275 mm
Stick Length 1160 mm
Boom Height – Shipping Position 1040 mm
Maximum Reach 3960 mm
Maximum Dig Height 3490 mm
Note *Overall Shipping Length depends on blade position during shipment.
Tail Swing 820 mm
O/A Undercarriage Length 1460 mm
Track Width – Expanded 1300 mm
Boom In Reach 1450 mm
O/A Shipping Height 2310 mm
Maximum Blade Depth 260 mm
Maximum Reach – Ground Level 3890 mm
Overall Shipping Length* 3590 mm
Maximum Dump Clearance 2510 mm
Swing Bearing – Height 445 mm
Minimum Ground Clearance Below Undercarriage 155 mm
Boom Swing – Left 65 °
Vertical Wall 1890 mm
Track Width – Retracted 990 mm
Track Belt/Shoe Width 230 mm
Boom Swing – Right 50 °

Dimension Standard Stick

Swing Bearing – Height 445 mm
O/A Undercarriage Length 1460 mm
Maximum Reach – Ground Level 3730 mm
Boom Swing – Left 65 °
Maximum Reach 3800 mm
O/A Shipping Height 2310 mm
Maximum Blade Depth 260 mm
Minimum Ground Clearance Below Undercarriage 155 mm
Vertical Wall 1800 mm
Dig Depth 2340 mm
Track Width – Expanded 1300 mm
Track Belt/Shoe Width 230 mm
Stick Length 960 mm
Maximum Dig Height 3430 mm
Overall Shipping Length* 3620 mm
Boom In Reach 1460 mm
Maximum Blade Height 275 mm
Maximum Dump Clearance 2450 mm
Boom Swing – Right 50 °
Note *Overall Shipping Length depends on blade position during shipment.
Boom Height – Shipping Position 1090 mm
Tail Swing 820 mm
Track Width – Retracted 990 mm

Travel System

Maximum Traction Force – High Speed 10.3 kN
Ground Pressure – Minimum Weight 27.3 kPa
Ground Pressure – Maximum Weight 30.6 kPa
Travel Speed – High 4.4 km/h
Travel Speed – Low 2.9 km/h
Maximum Traction Force – Low Speed 16 kN
Gradeability – Maximum 30 degrees

Blade

Height 225 mm
Note *Expanded – 1300 mm (51 in)
Width* 990 mm

Air Conditioning System

Air Conditioning The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 1.00 kg of refrigerant, which has a CO2 equivalent of 1.430 metric tonnes.
