Hangcha Forklift XE50 | 5 ton

Description

Hangcha Forklift XE50 | 5 ton

BELIALAT.COM support penjualan unit, parts, service, rental, maintenance contract, overhaul, reconditioned Hangcha Forklift XE50 | 5 ton

Hangcha Forklift XE50 | 5 ton, Specifications

The Hangcha XE50 (part of the XE Series) is a 5-ton electric forklift designed with specialized Lithium-ion technology.
It is often referred to as a “lithium-dedicated” forklift because it shares a chassis and heavy-duty components with internal combustion (IC) models, giving it the durability of a diesel truck with the efficiency of an electric one.
Below are the technical specifications for the Hangcha XE50 (CPD50-XEY2-SI):

Feature Specification

Rated Load Capacity 5,000 kg (5 Ton).
Load Center 600 mm.
Max Travel Speed (Laden/Unladen) 19 / 19 km/h.
Lift Speed (Laden/Unladen) 0.40 / 0.52 m/s.
Lowering Speed (Laden/Unladen) 0.37 / 0.42 m/s.
Gradeability (Laden/Unladen) 22% / 20%.

Battery & Electrical System

The XE50 utilizes a high-capacity 80V system, typically powered by CATL Lithium Iron Phosphate (LiFePO4) cells.
Voltage: 80V.
Standard Battery Capacity: 460Ah (Optional 604Ah available for heavy-duty shifts).
Charging Time: ~2.0 hours (with high-speed charger).
Drive Motor: 23 kW (Permanent Magnet Synchronous Motor).
Lift Motor: 28 kW.

Dimensions & Weight

Total Width: 1,490 mm.
Length to Face of Forks: ~4,120 – 4,300 mm.
Turning Radius: 2,740 mm.
Standard Lift Height: 3,000 mm (can be equipped with masts up to 7,000 mm).
Service Weight: Approx. 6,240 – 7,230 kg (depending on battery/mast).
Ground Clearance: Increased clearance compared to standard electrics for outdoor use.

Key Features

IPX4 Water Resistance: Designed to operate in heavy rain and outdoor conditions.
IC-Platform Design: Uses the same heavy-duty transmission, drive axle, and mast as Hangcha’s diesel series for better reliability in rugged environments.
Ergonomics: Features a color-screen display, optional electronic handbrake (EPB), and a low center of gravity for stable cornering.
Battery Heating: Standard module allows the battery to operate efficiently in cold storage or freezing temperatures (down to -30°C).
Would you like me to compare these specs against a similar diesel model or help you find a local dealer for pricing?

Characteristics

Engine : Electric Lithium Power
Operator Position : Sit on Type
Load Capacity : 5000 Kg

Load Center C : 500 mm
Alternative Capacity Q2 : 1350 mm
Load Distance X : 404 mm
Wheelbase Y : 1400 mm

Weight

Service Weight : 2550 mm
Axle Loading/Loaded/Front : 3530 kg
Loading/Loaded/Rear : 520 kg

Axle Loading/Unloaded/Front : 1035 kg
Axle Loading/Unloaded/Rear : 1515 kg

Dimensions

Tilting Angle α/β Forward/Backward degree : 6/10
accordingly Mast Height, Lowered h1 2-stage Mast : 1995 mm
Std Free Lift h2 2-stage std. Mast,From Ground : 140 mm
Std. Lift Height h3 2-stage Std. Mast,
From Ground : 3000 mm

MastHeight, Extended h4 2-stage. Mast : 3955 mm
above all Heigt, Overhead Guard h6 : 2070 mm
Length, with std. forks L1 : 3160 mm

Length, to forks Face L2 : 2240 mm
Width, at Tyre b1 Single : 1070 mm
Forks s/e/l Thicness x Width x Length : 35 x 100 x 920 mm

additionally Fork Carriage Class ISO 2328, Type A/B/no : Class 2,A mm
Width, Fork Carriage b2 : 970 mm
Ground Clereance m1 Under Mast : 120 mm

Ground Clereance m2 at Center of Wheelbase : 130 mm
Right Angle Stacking Aisle Ast with L1000x W800 Pallet : 3560 mm
Turning Radius Wa : 1955 mm

Performance

Travel Speed (FWD) Loaded 1st/2nd : 18.5 km/h
Travel Speed (FWD) Unloaded 1st/2nd : 19.0 km/h
Lifting Speed Loaded : 620 mm/s } | { Lifting Speed Unloaded : 670 mm/s

after all Lowering Speed Loaded : 500 mm/s
Lowering Speed Unloaded : 550 mm/s
Max. Drawbar Pull Loaded : 13 KN

Max. Gradeability Loaded % : 33 %
afterward Service Brake Operation/Control : Foot/Hydraulic
Parking Brake Operation/Control : Hand/Mechanical

Steering Type : FHPS
Battery Voltage/ Capacity at 5-hour rating V/ah : 12/64 Volt/ah

Tyre

size, front ( standard tread ) : 6.9-9-10PR
size, rear : 5.0-8-8PR

Dual tyre

Tread front ( dual tread ) : 1000 mm
Overall width : 1190 mm
Service weight ( dual tread ) :2690 kg
