Hangcha Towing Tractor HIC20 | 2 ton

Description

Hangcha Towing Tractor HIC20 | 2 ton

The Hangcha A Series Electric Towing Tractor (2 ton) is a compact and efficient material handling vehicle designed for transporting goods in warehouses, workshops, and production lines.
Below are the technical specifications for the 2-ton model (typically designated as QDD20 or within the A Series range):

Feature Specification

Rated Towing Capacity 2,000 kg (2.0 ton).
Rated Drawbar Pull 500 N.
Max. Drawbar Pull 2,000 N.
Travel Speed (Laden/Unladen) 6 / 13 km/h.
Turning Radius 1,600 mm.
Service Weight (inc. battery) ~880 kg.

Power & Battery

Drive Type: Electric (AC Traction Motor).
Motor Rating: ~1.95 kW – 2.0 kW (AC)
Voltage/Capacity: 48V / 165Ah (Standard).
Optional Battery: Lithium-Ion (LiFePO4) available, offering 2-hour rapid charging and higher efficiency.
Controller: Curtis AC or Inmotion (standard high-frequency integrated system).

Dimensions & Tyres

Overall Length: ~1,684 mm.
Overall Width: ~900 mm.
Ground Clearance: 100 mm.
lass=”yoast-text-mark” />>Tyre Type: Pneumatic (Solid rubber optional).
s=”yoast-text-mark” />>Tyre Size (Front): 3.50-5-6PR.
>Tyre Size (Rear): 4.00-8-6PR.

Key Features

Safety: Includes an Electronic Park Brake (EPB) as standard, automatic deceleration at turns, and an emergency power-off switch.
Operation: Available in both Seated and Stand-on configurations. Stand-on models often feature electronic power steering and a safety pedal (dead-man switch).
Convenience: Side-loading battery roll-out for quick swaps, LED lighting (headlights/tail lights), and a USB charging port for the operator.

Durability: Three-support-point design with a low center of gravity for stability, and a high-strength steel frame.
Note: If you are looking for the HIC specific naming (often associated with Internal Combustion or specific regional branding), please note that the 2-ton towing range from Hangcha is almost exclusively Electric (A Series) in modern catalogs.
