Heli Forklift CPCD35 | 3.5 ton

Description

Heli Forklift CPCD35 | 3.5 ton

The Heli CPCD35 is a diesel-powered, counterbalanced forklift designed for a 3.5-ton (3,500 kg) lifting capacity.
It is part of Heli’s internal combustion (IC) range, known for its reliability in industrial and outdoor applications.
Below are the primary technical specifications for the standard unit:

Performance & Capacity

Rated Capacity: 3,500 kg (3.5 Tons).
Load Center: 500 mm.
Standard Max Lifting Height: 3,000 mm (Up to 6,000 mm with optional Triplex mast).
Travel Speed (Loaded/Unloaded): Approx. 18–21 km/h.
Lifting Speed (Loaded): Approx. 460–500 mm/s.
Gradeability (Loaded): 15% – 20% (Standard) / up to 22% (Rough Terrain variants).

Dimensions & Weight

Overall Length (with forks): ~3,840 mm.
>Overall Width: 1,225 mm.
>Overall Height (to Overhead Guard): 2,170 mm.
Mast Lowered Height: 2,180 mm.
Turning Radius (Exterior): 2,420 – 2,440 mm.
Service Weight: Approx. 4,700 – 5,000 kg (varies by mast configuration).
Standard Fork Size: 1,070 mm x 125 mm x 50 mm.

Engine Options

The CPCD35 is often configured with different engines depending on the regional emission standards:
Common Engines: * Mitsubishi S4S: Robust and popular in Southeast Asia.
Kubota V2403: Common for Euro Stage V compliance.
Isuzu 4JG2: Known for durability and easy maintenance.
Quanchai 4C2: Standard budget-friendly option.
Rated Power: Typically ranges between 35 kW to 45 kW @ 2,450–2,500 rpm.
Fuel Tank Capacity: ~60–70 Liters.

Key Features

Safety: Equipped with an Operator Presence System (OPS) which locks lifting and traveling if the driver leaves the seat.
Comfort: Suspended overhead guard to reduce vibration, wide-view mast for better visibility, and adjustable steering column.
Tires: Standard pneumatic tires (Front: 28×9-15-14PR | Rear: 6.50-10-10PR); solid tires are optional.
