Heli Forklift CPCD85 | 8.5 ton

Description

Heli Forklift CPCD85 | 8.5 ton

The Heli CPCD85 is a heavy-duty diesel forklift from Heli’s G-Series, designed for high-intensity industrial applications like ports, construction, and large-scale manufacturing.
Below are the primary technical specifications for the 8.5-ton unit.

Core Performance

Rated Capacity: 8,500 kg (8.5 tons).
Load Center: 600 mm.
Standard Lift Height: 3,000 mm (can vary with optional masts).
Free Lift Height: 200 mm.
Max Travel Speed (Loaded/Unloaded): 24 / 28 km/h.
Lifting Speed (Loaded/Unloaded): 390 / 420 mm/s.
Max Gradeability (Full Load): 23%.

Engine & Transmission

The CPCD85 typically features robust industrial engines designed for high torque.
Common Engine Models: * Isuzu 6BG1: (6-cylinder, ~82 kW @ 2000 rpm).
CA6110: (6-cylinder, ~83 kW @ 2000 rpm).
Cummins QSF3.8: (Optional for specific emission standards).
Fuel Type: Diesel.
Transmission: Hydraulic (Power Shift), usually with 2 forward and 2 reverse speeds.

Physical Dimensions

Overall Length (with forks): ~5,180 mm.
>Overall Width: ~2,165 mm.
>Overall Height (to Overhead Guard): ~2,560 mm.
Minimum Turning Radius (Outer): 3,650 mm.
Ground Clearance (at Mast): 250 mm.
Service Weight: Approx. 11,550 kg.

Key Features

Hydraulic System: Uses dual-pump confluence technology to improve lifting speeds while reducing energy consumption.
Operator Comfort: Features a floating cab (roof guard) to dampen vibrations and an ergonomic seat with adjustable controls.
Safety: Includes an explosion-proof valve in the mast pipeline to prevent rapid descent if a hose fails, and a standard backup alarm/rotating beacon.
Note: Specifications can vary slightly depending on whether the unit is from the G-Series or the newer G3-Series.
