Heli Forklift CPD85 | 8.5 ton

Description

Heli Forklift CPD85 | 8.5 ton

The Heli CPD85 is a heavy-duty electric counterbalanced forklift from the G series (often featuring the G3 series updates).
It is designed as a powerful, zero-emission alternative to 8.5-ton diesel forklifts, specifically for large-scale manufacturing, ports, and heavy warehousing.
Below are the primary technical specifications for the Heli CPD85:

Core Performance

Rated Capacity: 8,500 kg (8.5 tons).
Load Center: 600 mm.
Power Type: Electric (Lead-acid or Lithium-ion options).
Max. Travel Speed (Laden/Unladen): 14 / 16 km/h.
Max. Lifting Speed (Laden/Unladen): 0.30 / 0.37 m/s.
Gradeability (Laden/Unladen): 15% – 20% (depending on configuration).

Dimensions & Weight

Overall Length (without forks): 3,580 mm.
Overall Width: 2,116 mm.
Overhead Guard Height: 2,445 mm.
Standard Max. Lifting Height: 3,000 mm (options available up to 7,000 mm).
Turning Radius (Outer): 3,140 mm.
Total Weight (including battery): Approximately 13,620 kg.

Battery & Motor Specs

Drive Motor Power: 17.1 kW (Dual drive system).
Lifting Motor Power: 26.5 kW.
System Voltage: 80V.
Battery Capacity: * Lead-Acid: Standard 80V / 1120Ah.
Lithium-Ion: High-performance options available (e.g., 80V / 808Ah or dual-gun fast charging configurations).

Key Features

Dual Drive System: Two independent AC motors provide high torque and precision handling.
Intelligent Safety: Includes automatic speed limitation during turns, an Operator Presence System (OPS), and automatic parking brakes.
Visibility: Features a wide-view mast and a low-profile counterweight design to optimize the rear-view field for the driver.
Maintenance: Maintenance-free wet disc brakes and easy side-access for battery extraction.
