Heli Order Picker JX12J | 1.2 ton

Description

Heli Order Picker JX12J | 1.2 ton

The Heli JX12J is a low-level electric order picker designed for efficient horizontal transport and picking operations in warehouses.
It features a robust 1.2-ton capacity and is optimized for narrow-aisle maneuverability.
Below are the primary technical specifications for the unit:

Core Performance

Rated Capacity: 1,200 kg.
Load Center: 600 mm.
Max Lift Height: 700 mm (designed for low-level picking).
Travel Speed: 5.2 km/h (laden) / 5.5 km/h (unladen).
Lifting Speed: 95 mm/s (laden) / 160 mm/s (unladen).
Gradeability: 3% (laden) / 6% (unladen).

Physical Dimensions

Overall Length: 2,551 mm.
>Overall Width: 808 mm.
>Overall Height: 1,253 mm.
Turning Radius: 2,076 mm.
Aisle Width (1000×1200 pallet): 2,960 mm.
Service Weight: Approx. 1,070 kg (including battery).

Power & Drive System

Battery Voltage/Capacity: 24V / 360Ah.
Drive Motor: 1.5 kW (AC).
Lift Motor: 2.2 kW (DC).
Controller: CURTIS AC Controller.
Brake Type: Electromagnetic brake.
Steering: Electronic Power Steering (EPS).

Key Features

AC Drive System: Provides smooth acceleration, high efficiency, and low maintenance compared to DC systems.
Side-Extraction Battery: Allows for quick battery swaps during multi-shift operations.
Safety Features: Includes an emergency stop button, automatic speed reduction during turns, and a lifting limit function.
Ergonomics: Stand-on platform with a low step-in height to reduce operator fatigue during frequent entries and exits.
