Hyundai Forklift 16B-9 | 1.6 ton

The Hyundai 16B-9 is a 1.6-ton electric 4-wheel counterbalance forklift from Hyundai’s 9-Series.
It is designed for high-efficiency indoor operations, combining a compact chassis with advanced AC drive technology.
Below are the primary technical specifications for the unit:

Performance & Capacity

Load Capacity 1.6 tons (1,600 kg).
Load Center 500 mm.
Travel Speed (Loaded/Unloaded) 16 / 17 km/h.
Lift Speed (Loaded/Unloaded) 410 / 600 mm/s.
Max Gradeability (Loaded) 29.5%.
Turning Radius 1,710 mm.

Dimensions & Weight

Overall Width: 1,074 mm.
Overall Length (to fork face): 2,035 mm.
Overhead Guard Height: 2,065 mm.
Standard Lift Height: 3,325 mm (varies by mast choice).
Service Weight (with battery): Approx. 3,150 kg.
Ground Clearance (under mast): 85 mm.

Electrical System

Battery Voltage: 48V.
Battery Capacity: 510 Ah (standard).
Drive Motors: Dual 4.7 kW x 2 AC motors.
Pump Motor: 14.0 kW AC motor.
Controller: ZAPI AC High-Frequency Controller.

Key Features & Safety

Dual Drive System: Uses two separately controlled motors for the front wheels, improving traction on slippery floors and allowing for a tighter turning radius.
Curve Control: Automatically limits travel speed based on the turning radius to prevent tipping.
Anti-Roll Back: Prevents the forklift from rolling backward when starting on a ramp.
Operator Presence Sensing System (OPSS): Disables hydraulic and travel functions if the operator is not seated.
Brake System: Maintenance-free Wet Disc Brakes (oil-cooled) for consistent stopping power.
LCD Monitor: A 3.5-inch color display providing real-time data on speed, steering angle, and battery level.

Mast Options

While the standard lift is ~3.3m, the 16B-9 can be equipped with:
2-Stage Limited Free Lift (V): Standard warehouse use.
2-Stage Full Free Lift (VF): Low ceiling areas (containers).
3-Stage Full Free Lift (TF): High-reach stacking (up to 7,000 mm).
