Hyundai Forklift 18B-9 | 1.8 ton

Description

Hyundai Forklift 18B-9 | 1.8 ton

The Hyundai 18B-9 is a 4-wheel electric counterbalance forklift designed for high efficiency and maneuverability in indoor or tight-space applications.
It is part of Hyundai’s “9-Series,” known for its advanced ergonomics and the use of dual-drive AC motors.
Below are the primary technical specifications for the 1.8-ton (1,800 kg) model:

Core Specifications

Load Capacity 1,800 kg (1.8 ton).
Load Center 500 mm.
Power Type Electric (48V Battery).
Drive System Dual AC Front Drive Motors.
Service Weight ~3,275 kg (with battery).
Turning Radius 1,795 mm.

Performance & Drive

Travel Speed: 16 km/h (loaded) / 17 km/h (unloaded).
Lifting Speed: 410 mm/s (loaded) / 600 mm/s (unloaded).
Gradeability: 21.0% (loaded).
Braking: Maintenance-free Wet Disc Brakes (enclosed to protect against dust and water).
Drive Motors: $2 \times 4.7$ kW dual drive motors for better traction and a tighter turning circle.

Dimensions

Overall Width: 1,105 mm.
Length to Fork Face: 2,120 mm.
Overhead Guard Height: 2,065 mm.
Standard Fork Size: 35 x 100 x 900 mm (options up to 1500 mm).
Tires: Superelastic (Solid) – Front: 200/50-10, Rear: 16×6-8.

Key Features & Technology

Curve Control: Automatically reduces travel speed during turns based on the steering angle to prevent tipping.
Anti-Roll Back: Prevents the truck from rolling backwards when starting on a ramp or incline.
Operator Presence Sensing (OPSS): Disables hydraulic and drive functions if the operator leaves the seat.
LCD Monitor: 3.5-inch color display showing battery status, speed, steering angle, and diagnostic codes.
Battery Side Loading: Optional system for quick battery swaps using a roller-type assembly.
Note: Performance can vary slightly depending on the mast type (e.g., Simplex, Duplex, or Triplex) and the battery capacity (typically ranging from 510Ah to 600Ah).
