Hyundai Forklift 30B-9U | 3 ton

Description

Hyundai Forklift 30B-9U | 3 ton

The Hyundai 30B-9U is a high-performance, 4-wheel electric counterbalance forklift designed for versatility in warehouses and logistics. Part of the “9U-Series,” it is known for being Li-ion ready and featuring a dual-drive motor system for better maneuverability.
Below are the key specifications for the 3-ton (3,000 kg) model:

General Specifications

Model: 30B-9U.
Load Capacity: 3,000 kg (3 tons).
Load Center: 500 mm.
Power Source: Electric (Battery).
Tire Type: Solid / Superelastic (Standard).

Performance & Drive

Drive Motor: Dual AC motors (typically 2 x 7.0 kW or 14 kW total).
Lifting Motor: 17.0 kW.
Travel Speed (Loaded/Unloaded): 17 / 18 km/h.
Lifting Speed (Loaded/Unloaded): 0.34 / 0.50 m/s.
Gradeability (Loaded): Approx. 26% (14.5°).
Braking System: Maintenance-free Wet Disc Brakes.

Dimensions & Weights

Overall Width: 1,200 mm.
Overall Length (to face of forks): ~2,480 mm (standard configuration).
Turning Radius: 2,150 mm – 2,200 mm.
Overhead Guard Height: 2,230 mm.
Service Weight (with battery): Approx. 4,630 kg.

Battery Options

The “U” in the series signifies it is optimized for modern battery technology:
Voltage: 48V.
Lead-Acid Capacity: 810 Ah to 900 Ah.
Lithium-Ion Option: 564 Ah (High-efficiency, rapid charging).
Extraction: Lateral (Side) battery removal is standard for quick swaps.

Key Features of the 9U-Series

Curve Control: Automatically reduces travel speed during turns to prevent tipping.
EHPS (Electro-Hydraulic Power Steering): Provides smooth steering while reducing energy consumption by up to 17%.
Advanced LCD Monitor: A 4.3-inch color display that provides real-time diagnostics, weight indicators, and performance mode selection (H/N/E).
OPSS (Operator Presence Sensing System): Restricts mast and drive movements if the operator is not seated.
