JCB Backhoe Loader ICX | 3.2 ton

Description

JCB Backhoe Loader ICX | 3.2 ton

The JCB 1CX is the smallest model in JCB’s backhoe loader range.
>It is a unique hybrid machine that combines the maneuverability of a skid steer with the digging capability of a mini excavator.
>While it is often categorized in the 3-ton class, its specific weight varies between 2.8 and 3.25 tons depending on the configuration (e.g., fixed vs. extending dipper).

Key Technical Specifications

Feature Specification (Wheeled Model);
Operating Weight 2,850 kg – 3,254 kg (approx. 3.2 tons).
Engine Perkins 404D-22 (4-Cylinder Diesel).
Gross Power 37.3 kW (50 hp) @ 2,800 rpm.
Transmission Full Servo Hydrostatic
Travel Speed 11 km/h.
Shovel Capacity 0.28 m3.
Loader Lift Capacity 600 kg – 610 kg.

Performance Dimensions

The 1CX is designed for extremely tight spaces, capable of turning on its own axis.
>Excavation (Backhoe):
Max Dig Depth: 2.55 m (Standard) / 3.08 m (Extending Dipper)
Max Reach (at ground): 3.38 m (Standard) / 3.91 m (Extending).
Loadover Height: 2.35 m.
Loading (Front End):
Dump Height: 2.10 m.
Load Over Height: 2.51 m – 2.59 m.
Breakout Force (Shovel): 2,350 kgf.

Key Features

Maneuverability: Uses a skid-steer style drivetrain, allowing for a zero-turn radius.
>Versatility: Equipped with a universal skid steer quick-hitch on the front, making it compatible with a massive range of attachments (augers, sweepers, etc.).
>Sideshift Backhoe: The rear excavator arm is mounted on a sliding frame, allowing you to dig right up against walls or fences.
>Operator Comfort: Available with a full ROPS/FOPS glazed cab or a canopy.7 It features a swiveling seat to switch between loader and backhoe controls easily.
>Note: If you are looking for the tracked version, that model is the JCB 1CXT, which offers better flotation and stability on soft ground but has a slightly higher operating weight.
