TCM Order Picker LOS200 | 2 ton

Description

TCM Order Picker LOS200 | 2 ton

The TCM LOS200 is a low-level order picker specifically designed with a scissor lift mechanism. This allows the operator and the load to be raised to an ergonomic picking height (typically for first and second-level picking), significantly reducing physical strain during intensive warehouse operations.

Below are the key specifications and technical details for the 2-ton (2,000 kg) model:

Technical Specifications

Feature Specification.
Model LOS200.
Load Capacity 2,000 kg (2.0 Ton).
Lift Height (Forks) 900 mm.
Truck Width 790 mm.
Truck Length 1,536 mm (+ fork length).
Power Source Electric (AC Motor).
Chassis Type Scissor Lift (Low-level picker).
Travel Speed Approx. 12 km/h (varies by load).

Key Performance & Design Features

Ergonomic Scissor Lift: Unlike standard pallet trucks, the scissor mechanism raises the pallet to a waist-high level (up to 900 mm). This is ideal for “picking and placing” because it eliminates the need for the operator to bend down constantly.
Friction Force Technology: This system automatically adjusts the pressure on the drive wheel based on the load weight. This provides 35% more traction, ensuring the truck doesn’t slip during acceleration or braking.
Maneuverability: With a narrow chassis width of only 790 mm, the LOS200 is built for high-density warehouses with narrow aisles.

Operator Comfort:

Low Step-in Height: Reduces fatigue for operators who frequently get on and off the machine.
Spacious Platform: Includes a floating floor to dampen vibrations and a comfortable backrest.
Optional Power Steering: Allows for effortless control with a mini-steering wheel or motorbike-style handle.

Safety & Maintenance

Built-in Diagnostics: The onboard computer features a troubleshooting system that identifies faults quickly to minimize downtime.
PIN Code Access: Prevents unauthorized use and allows the machine to save specific performance settings for different operators.
Safety Floor: The entire platform acts as a “dead-man switch”; the truck will not move unless the operator is securely positioned on the platform.
