TCM Power Stacker SST100 | 1 ton

Description

TCM Power Stacker SST100 | 1 ton

The TCM SST100 is a heavy-duty, sit-on telereach stacker designed specifically for high-intensity warehouse operations and narrow-aisle environments.
Its standout feature is its telescopic forks, which allow it to handle double-deep racking or load/unload trucks from a single side.

Below are the technical specifications for the 1-ton (1,000 kg) configuration.

Technical Specifications: TCM SST100

Feature Specification.
Load Capacity 1,000 kg (1.0 Ton).
Model Series SST (Sit-on Telereach Stacker).
Maximum Lift Height Up to 6,300 mm (6.3 m).
Truck Width 1,010 mm.
Power Source 24V Electric (Lead-Acid or Li-Ion options).
Drive Motor High-efficiency AC motor (brushless).
Steering 360° Electric power steering.
Travel Speed Up to 10 km/h (varies by load/settings).

Key Features & Performance

Double-Deep Handling: Equipped with telescopic forks, the SST100 can reach into double-deep racking, potentially increasing storage density by up to 30%.
Operator Ergonomics: As a sit-on model, it is designed for long shifts.
It features an adjustable floor height, a midi steering wheel, and an ergonomic armrest to reduce driver fatigue.
Advanced Safety: * Stability Control: The truck automatically adjusts speed based on the steering angle for safer cornering.
Vision: The overhead guard pillar is designed with slots to eliminate blind spots, ensuring a clear view of the fork tips.

Driving Modes: Includes three pre-set performance profiles:

PRO: For experienced drivers in high-speed operations.
ECO: Optimized for the lowest energy consumption.
EASY: Limited speed (max 8 km/h) and softer braking for beginners or fragile goods.

Battery & Maintenance

Li-Ion Technology: Available with Lithium-ion batteries which support “opportunity charging” (charging during breaks) and offer roughly 25% more runtime than traditional lead-acid batteries.
Self-Diagnostics: The onboard computer features a built-in troubleshooting system to simplify maintenance and maximize uptime.
Note: Performance may vary depending on the specific mast type chosen (e.g., Triplex masts are standard for reaching the 6.3m height).
