Toyota Towing Tractor 4CBT2R | 2 ton

Description

Toyota Towing Tractor 4CBT2R | 2 ton

BELIALAT.COM support unit, parts, service, rental, maintenance contract, overhaul, reconditioned Toyota Towing Tractor 4CBT2R | 2 ton

The Toyota 4CBT2R is a compact, electric stand-up towing tractor designed for high-efficiency horizontal transport, commonly used in narrow aisles and frequent “on-off” applications like mail sorting or light manufacturing.

Key Specifications

Model 4CBT2R.
Drive Type Electric (AC Motor).
Operator Position Stand-up.
Towing Capacity 2,000 kg (2.0 ton).
Voltage 24V.
Travel Speed (Full Load) Approx. 9.0 km/h.
Travel Speed (No Load) Approx. 13.0 km/h.
Turning Radius 1,230 mm.

Technical Features & Performance

AC Drive System: Utilizes an AC motor that provides smooth acceleration and consistent travel speeds, even when carrying a full 2-ton load. It also reduces maintenance by eliminating motor brushes.
Compact Maneuverability: With a turning radius of just 1,230 mm, it is exceptionally agile in tight warehouse corners.
Regenerative Braking: This system reclaims energy back into the battery during deceleration, extending the operating time per charge.
Ergonomics: The stand-up configuration features a low floor height to reduce operator fatigue during frequent mounting and dismounting.

Dimensions & Weight

Overall Length: Approx. 1,465 mm.
Overall Width: 800 mm.
Floor Height: 175 mm (for easy entry/exit).
Service Weight: Approx. 780 kg (excluding battery).
Note: Performance specifications can vary slightly depending on the battery weight and the type of hitch/coupler installed on the rear of the unit.
Would you like me to look up the specific fluid capacities or battery compartment dimensions for this model?

Main Specification Toyota Towing Tractor 4CBT2R | 2 ton

Toyota Towing Tractor 4CBT2R | 2 ton

Model : 4CBT2R.
Operator Position : Sit-down.
Maximum Drawbar Pull (3-Minute Ratings) : 17640 (1800) N (kg).
Towed Weight 60-Minute Ratings : 2000 kg.
Overall Width A : 1420 mm.
Turning Radius (Outside) : 1600 mm.
Overall Height : 1185 mm.
Height (with cabin) B : 1325 (1895) mm.
Length (with hitch) C : 3615 mm.
Turning Radius (Outside) D : 3295 mm.
Battery Voltage/Capacity (5-hour ratings) : 80/445 V/AH.
Electric Motor : 16.6 kw.
