Toyota Towing Tractor 7CBTY06 | 0.6 Ton

BELIALAT.COM support unit, parts, service, rental, maintenance contract, overhaul, reconditioned Toyota Towing Tractor 7CBTY06 | 0.6 Ton

The Toyota 7CBTY06 is an electric-powered, stand-up towing tractor designed for indoor material handling and towing light loads in narrow spaces.
It is part of Toyota’s 7-Series and is valued for its extremely compact turning radius.
Below are the key specifications for this unit:

Feature Specification Toyota Towing Tractor 7CBTY06 | 0.6 Ton

Operator Position Stand-up (Rider).
Towed Weight (60-min rating) 600 kg (0.6 ton).
Max Drawbar Pull (3-min rating) 450 N (45 kgf).
Rated Drawbar Pull (60-min rating) 150 N (15 kgf).
Travel Speed (No Load / Loaded) 8.5 km/h / 7.5 km/h.
Gradeability (3-min rating) 16%.

Dimensions & Weight

Feature Specification;
Overall Length (with Hitch) 1,505 mm.
Overall Width 745 mm.
Overall Height 1,195 mm.
Turning Radius (Outside) 1,510 mm.
Floor Height (Step height) 135 mm.
Wheelbase 950 mm.
Total Weight (including battery) Approx. 220 kg.

Electrical System & Drive

Motor: DC 0.4 kW Drive Motor.
Battery: 24V / 100Ah (5-hour rating).
Control Type: Field Effect Transistor (FET) Chopper.

Key Features

Compact Design: Ideal for narrow aisles and facilities where space is at a premium.
Operator Presence Sensing (OPS): Automatically cuts travel power if the operator is not in the normal operating position.
Ergonomics: Low step height (135 mm) for frequent “on-and-off” tasks, reducing operator fatigue.
Tires: Usually equipped with a Pneumatic-shaped Cushion tire at the front and Pneumatic tires at the rear.
Would you like me to compare these specs with the sit-down version (7CBT06) or help you find a manual for this model?

Toyota Towing Tractor 7CBTY06 | 0.6 Ton, Specifications

Manufacturer : Toyota.
Model: 7CBTY06, Power Type : Battery.
Operator Position : Stand-Up.

Tire Type : Pneumatic-shaped Cushion Tire/ Pneumatic.
Wheels (x = driven) : 1/2x.
Maximum Drawbar Pull 3-Minute Ratings N <kg> : 450 <45>.

Rated Drawbar Pull (Towing Capacity) 60-Minute Ratings : 150 <15> N <kg>.
Towed Weight 60-Minute Ratings : 600 kg.
Travel Speed No Load : 8.5 Km/h.

Travel Speeds w/ Load : 7.5 Km/h.
Gradeability * 3-Minute Ratings No Load : 16 % (tanθ).
Overall Length w/ Hitch : 1505 mm.

Overall Length w/o Hitch : 1415 mm
Front Overhang : 240 mm
Rear Overhang : 225 mm

Hitch Length : 90 mm.
Overall Width : 745 mm,
Overall Height : 1195 mm,

Turning Radius (Outside) : 1510 mm,
Height of Hitch : 260 mm,
Wheelbase : 950 mm,

Tread Front : -,
Trad Rear : 590 mm,
Underclearance Center of Wheelbase : 65 mm,

Floor Height : 135 mm,
Total Weight w/ Battery : 220 kg,
Total Weight Without Battery : 150 kg,

Weight Distribution (With STD Battery) Front : 70 kg,
Weight Distribution (With STD Battery) Rear : 150 kg,
Tires Number Front/Rear : 1/2,

size front : 3.00-5.
size rear : 3.50-5-6PR (I),
Brake Service (Hand) : Mechanical,

Brake Parking (Hand) : Mechanical,
Battery Voltage/Capacity (5-Hour Ratings) STD : 24/100 V/Ah,
Battery Weight (STD Capacity Type) : 70 Kg,

Electric Motor Drive : DC 0.4 kw,
Control Type Drive : Field Effect Transistor Chopper
