Case Excavator CX800B | 80 ton

Description

Case Excavator CX800B | 80 ton

BELIALAT.COM support, unit, parts, service, rental, maintenance contract, overhaul, rconditioned Case Excavator CX800B | 80 ton

The Case CX800B is an 80-metric-ton heavy-duty crawler excavator built for mass excavation, heavy quarrying, and high-production earthmoving environments.

Comprehensive unit specifications and performance metrics for the Case CX800B include:

General Specifications & Weights

• Operating Weight: 80,300 kg / 178,574 lbs (80.3 Metric Tons)

• Counterweight: 12,561 kg / 27,668 lbs

• Bucket Capacity Range: 1.93 m³ to 4.52 m³ (depending on attachment density)

Engine Technical Data

• Engine Manufacturer & Model: Isuzu AH-6WG1XYSS

• Type: Water-cooled, 4-cycle diesel, 6-cylinder in-line, direct injection with turbocharger and air-cooled intercooler

• Emission Level: Tier 3 Certified (Note: Later regional production updates integrate Tier 4 Final configurations).

• Net Power: 532 hp (397 kW) @ 1,800 rpm

• Maximum Torque: 2,250 Nm @ 1,500 rpm

• Displacement: 15.7 Liters (15,700 cc)

• Bore x Stroke: 147 mm x 154 mm

Hydraulic System

• Main Pumps: 2 Variable-flow axial piston pumps

• Maximum Oil Flow: 2 x 500 L/min (approx. 264.2 gal/min total flow)

• System Relief Pressure: 314 bar (4,554 psi)

• Auto Power Boost Pressure: 343 bar (4,975 psi)

• Work Modes: 3 Selectable Modes (Auto, Heavy, and Speed Priority/Super Power)

Working Ranges & Excavation Performance

(Performance varies depending on whether the unit is equipped with the Standard 8.40m Boom or the 7.25m Mass Excavation Boom configuration):

• Max Horizontal Reach: Up to 14.3 m to 16.11 m (depending on arm extension)

• Max Digging Depth: Up to 10.66 m (35 ft)

• Bucket Rotation: 162° to 167°

• Arm Tear-out / Breakout Force: 214 kN to 330 kN (up to 347 kN with Auto Power Boost enabled)

Drivetrain & Undercarriage

• Travel System: 2-speed hydrostatic dual-path drive

• Maximum Travel Speed: 5.6 km/h (3.5 mph)

• Swing Mechanism Speed: 6.4 rpm

• Track Length: 6.36 m (20 ft 10 in)

• Track Gauge (Width Between Centers): 3.64 m (11 ft 11 in)

• Standard Shoe Width Options: 650 mm / 750 mm / 900 mm (2-bar steel shoes, 51 per side)

Service Capacities

• Fuel Tank: 900 Liters (237.8 gal)

• Hydraulic System Capacity: 720 Liters (190.3 gal)

• Hydraulic Tank: 310 Liters (81.9 gal)

• Engine Oil (with Filter Change): 52 Liters (13.8 gal)

Core Standard Features

• Extended Maintenance System (EMS): Provides highly durable pins and bushings extending lubrication intervals to 1,000 hours for main joint pins (except bucket pins at 250 hours).

• Hydraulic Reversing Cooling Fan: Automatically cleans dust and debris out of the radiators upon start-up.

• Operator Cab: High-visibility fluid-mount isolated cab featuring self-adjusting climate control, LCD monitor diagnostic display, storable lower windshield, and full 4-point shock absorption.
