Caterpillar Skid Loader 242D3 | 3.2 ton

Description

Caterpillar Skid Loader 242D3 | 3.2 ton

BELIALAT.COM support unit, parts, service, rental, maintenance contract, overhaul, reconditioned Caterpillar Skid Loader 242D3 | 3.2 ton

Specification unit Caterpillar Skid Loader 242D3 | 3.2 ton

ENGINE

Gross Power 45.5 kW
Gross Power – SAE J1995:2014 45.5 kW.

Displacement 2.2 l
Stroke 100 mm.

Bore 84 mm
Engine Model Cat® C2.2 T
Net Power – SAE 1349/ISO 9249 42 kW

OPERATING DESCRIPTIONS

Rated Operating Capacity 680 kg
Rated Operating Capacity with Optional Counterweight 726 kg
Tipping Load 1360 kg
Breakout Force – Tilt Cylinder 1852 kg

Note Operating Weight, Operating Specifications and Dimensions all based on 75 kg (165 lb) operator, all fluids, 1 speed, OROPS, dirt bucket, tires, no optional counterweights and manual quick coupler (unless otherwise noted).

WEIGHT

Operating Weight 2641 kg
Note : Operating Weight, Operating Specifications and Dimensions all based on 75 kg (165 lb) operator, all fluids, 1 speed, OROPS, dirt bucket, tires, no optional counterweights and manual quick coupler (unless otherwise noted).

DIMENSIONS

Wheel Base 986 mm
Length – With Bucket on Ground 3233 mm.

Length – Without Bucket 2519 mm
Height – Top of Cab 1950 mm.

Vehicle Width over Tires 1525 mm
Maximum Overall Height 3709 mm.

Bucket Pin Height – Maximum Lift 2854 mm
Bucket Pin Height – Carry Position 200 mm

Reach – Maximum Lift/Dump 505 mm
Clearance at Maximum Lift and Dump 2169 mm

Ground Clearance 195 mm
Departure Angle 26°
Maximum Dump Angle 40°

Turn Radius from Center – Coupler 1195 mm
Turn Radius from Center – Bucket 1944 mm
Rack Back Angle – Maximum Height 81°

Bumper Overhang – Behind Rear Axle 967 mm
Maximum Reach with Arms Parallel to Ground 1291 mm

Note Operating Weight, Operating Specifications and Dimensions all based on 75 kg (165 lb) operator, all fluids, 1 speed, OROPS, dirt bucket, tires, no optional counterweights and manual quick coupler (unless otherwise noted).

CABIN

ROPS ISO 3471:2008
FOPS ISO 3449:2005 Level I

SERVICE REFILL CAPACITIES

Chain Box – Each Side 6 L
Cooling System 10 L
Engine Crankcase 10 L
Fuel Tank 58 L
Hydraulic System 55 L
Hydraulic Tank 35 L

HYDRAULIC SYSTEM

Hydraulic Flow – High Flow – Hydraulic Power (Calculated) 37.7 kW
Hydraulic Flow – High Flow – Loader Hydraulic Flow 104 L/min
Hydraulic Flow – High Flow – Loader Hydraulic Pressure 23000 kPa
Hydraulic Flow – Standard – Loader Hydraulic Flow 61 L/min
Hydraulic Flow – Standard – Loader Hydraulic Pressure 23000 kPa
Hydraulic Flow – Standard – Hydraulic Power (Calculated) 23.2 kW

POWER TRAIN

Travel Speed – Forward or Reverse 12.7 km/h
