Hangcha Forklift XE45 | 4.5 ton

Description

Hangcha Forklift XE45 | 4.5 ton

BELIALAT.COM support penjualan unit, parts, service, rental, maintenance contract, overhaul, reconditioned Hangcha Forklift XE45 | 4.5 ton

Hangcha Forklift XE45 | 4.5 ton, Specifications

The Hangcha XE45 is a 4.5-ton electric forklift designed with a dedicated lithium-ion chassis.
It is part of the XE series, which bridges the gap between traditional indoor electric forklifts and heavy-duty internal combustion (IC) trucks by using a permanent magnet synchronous motor (PMSM) system.

Feature Specification

Rated Load Capacity 4,500 kg (4.5 tons).
Load Center 500 mm.
Drive Type Electric (Lithium-ion / LiFePO4).
Standard Battery 80V / 460Ah (CATL or EVE options available).
Travel Speed 19 km/h (Laden / Unladen).
Lift Speed ~0.43 m/s (Laden) / 0.55 m/s (Unladen).
Turning Radius 2,680 mm.
Service Weight Approx. 6,280 kg.

Dimensions & Maneuverability

Overall Width: 1,490 mm.
Mast Height (Lowered): 2,350 mm (Standard Simplex Mast).
Standard Lift Height: 3,000 mm (Options available up to 7,000 mm).
Ground Clearance: 155 mm (High clearance design for outdoor use).
Gradeability: Up to 22% (Laden).

Key Features of the XE Series

Dual Motor System: Equipped with two high-efficiency permanent magnet synchronous motors (23 kW traction / 28 kW hoist), which reduce energy consumption by 15–20% compared to traditional AC motors.
All-Weather Performance: The unit features IPX4 water resistance, making it capable of working in heavy rain.8 It also includes an automatic battery heater for cold-weather operations.
Fast Charging: Lithium-ion technology allows for a full charge in roughly 2 hours and supports “opportunity charging” (charging during breaks without damaging the battery life).
IC-Truck Durability: Unlike standard electric forklifts, the XE45 uses heavy-duty axles, gearboxes, and larger tires typically found on diesel forklifts, allowing it to handle rougher outdoor terrain.
Ergonomics: Features a color-screen instrument panel, a spacious cabin, and optional electronic handbrakes and fingertip controls.
Would you like me to find a local dealer for pricing or provide a comparison between the XE45 and the diesel equivalent (XF Series)?

Characteristics

Engine : Electric Lithium Power
Operator Position : Sit on Type
Load Capacity : 4500 Kg

Load Center C : 500 mm
Alternative Capacity Q2 : 1350 mm
Load Distance X : 404 mm
Wheelbase Y : 1400 mm

Weight

Service Weight : 2550 mm
Axle Loading/Loaded/Front : 3530 kg
Loading/Loaded/Rear : 520 kg

Axle Loading/Unloaded/Front : 1035 kg
Axle Loading/Unloaded/Rear : 1515 kg

Dimensions

Tilting Angle α/β Forward/Backward degree : 6/10
accordingly Mast Height, Lowered h1 2-stage Mast : 1995 mm
Std Free Lift h2 2-stage std. Mast,From Ground : 140 mm
Std. Lift Height h3 2-stage Std. Mast,
From Ground : 3000 mm

MastHeight, Extended h4 2-stage. Mast : 3955 mm
above all Heigt, Overhead Guard h6 : 2070 mm
Length, with std. forks L1 : 3160 mm

Length, to forks Face L2 : 2240 mm
Width, at Tyre b1 Single : 1070 mm
Forks s/e/l Thicness x Width x Length : 35 x 100 x 920 mm

additionally Fork Carriage Class ISO 2328, Type A/B/no : Class 2,A mm
Width, Fork Carriage b2 : 970 mm
Ground Clereance m1 Under Mast : 120 mm

Ground Clereance m2 at Center of Wheelbase : 130 mm
Right Angle Stacking Aisle Ast with L1000x W800 Pallet : 3560 mm
Turning Radius Wa : 1955 mm

Performance

Travel Speed (FWD) Loaded 1st/2nd : 18.5 km/h
Travel Speed (FWD) Unloaded 1st/2nd : 19.0 km/h
Lifting Speed Loaded : 620 mm/s } | { Lifting Speed Unloaded : 670 mm/s

after all Lowering Speed Loaded : 500 mm/s
Lowering Speed Unloaded : 550 mm/s
Max. Drawbar Pull Loaded : 13 KN

Max. Gradeability Loaded % : 33 %
afterward Service Brake Operation/Control : Foot/Hydraulic
Parking Brake Operation/Control : Hand/Mechanical

Steering Type : FHPS
Battery Voltage/ Capacity at 5-hour rating V/ah : 12/64 Volt/ah

Tyre

size, front ( standard tread ) : 6.9-9-10PR
size, rear : 5.0-8-8PR

Dual tyre

Tread front ( dual tread ) : 1000 mm
Overall width : 1190 mm
Service weight ( dual tread ) :2690 kg
