Hyundai Forklift 35D-9 | 3.5 ton

Description

Hyundai Forklift 35D-9 | 3.5 ton

BELIALAT.COM support unit, parts, service, rental, maintenance cotract, overhaul and reconditioned Hyundai Forklift 35D-9 | 3.5 ton

Technical Specifications Summary

1. Performance & Capacity

• Rated Load Capacity: 3,500 kg (7,700 lbs / 3.5 tonnes)

• Load Center Distance: 500 mm (20 in)

• Standard Lift Height: 3,000 mm (118 in / 9.8 ft) (optional masts available up to 7,000 mm)

• Travel Speed (Loaded / Unloaded): ~24.5 km/h (15.2 mph) / ~25.5 km/h (15.8 mph)

• Lift Speed (Loaded / Unloaded): 510 mm/s / 550 mm/s

• Lowering Speed (Loaded / Unloaded): 500 mm/s / 450 mm/s

• Gradeability (Loaded, at 1.6 km/h): 33.5% to 37.8%

2. Engine & Drivetrain

• Engine Model: Kubota V3800-CR-TE4B / Hyundai HMC D4BB (Tier 4 Final / Stage IV compliant depending on regional emission specs)

• Engine Type: 4-Cylinder, In-line, Water-Cooled Diesel Engine

• Rated Output (Power): ~74 HP (55 kW) @ 2,200 RPM

• Maximum Torque: ~310 Nm @ 1,400 RPM

• Displacement: 3,769 cc (3.8L)

• Transmission Type: Power Shift Automatic Transmission (2 forward / 2 reverse speeds)

3. Dimensions & Weight

• Operating Weight: Approx. 5,090 kg (11,220 lbs)

• Overall Length to Face of Forks: 2,860 mm (112.6 in)

• Overall Width: 1,370 mm (53.9 in)

• Overhead Guard Height: 2,230 mm (87.8 in)

• Mast Lowered Height (Standard 3m Mast): 2,220 mm (87.4 in)

• Wheelbase: 1,750 mm (68.9 in)

• Ground Clearance (Lowest Point – Mast): 145 mm (5.7 in)

• Turning Radius (Outside): 2,640 mm (103.9 in)

• Right Angle Stacking Aisle Width: ~4,480 mm (includes load allowance)

4. Tires & Wheels

• Drive Tires (Front): Pneumatic 250-15-18PR (Dual front tires optional)

• Steer Tires (Rear): Pneumatic 6.50-10-10PR

• Brake Type: Wet Disc Brakes (Maintenance-free enclosed system)

5. Hydraulic & Tank Capacities

• Hydraulics System Pressure: 210 bar (3,045 PSI)

• Fuel Tank Capacity: 70 Liters (18.5 Gal)

• Hydraulic Oil Tank Capacity: 62 Liters (16.4 Gal)

Key Features & Standard Equipment

• Operator Environment: Full suspension comfort seat, tilt steering wheel, low-noise acoustic design, and color LCD monitor with diagnostic reporting.

• Safety Systems: Auto-fork leveling system, OPSS (Operator Presence Sensing System), and speed limiter setting.

• Cooling & Durability: Heavy-duty aluminum radiator with wide-core fin spacing to prevent clogging during outdoor operations.
