Hyundai Hand Pallet 30HP | 3 ton

Description

Hyundai Hand Pallet 30HP | 3 ton

The Hyundai 30HP is a heavy-duty, manual hydraulic hand pallet truck designed for professional material handling.
With a robust 3-ton (3,000 kg) capacity, it is typically used in high-volume warehouses and industrial environments where durability is a priority.
Below are the detailed specifications for the unit:

Core Specifications

Model 30HP.
Load Capacity 3,000 kg (3 Ton).
Operation Type Manual / Hand-operated.
Service Weight Approx. 63 kg.
Turning Radius 1,266 mm.
Load Center 600 mm.

Dimensions & Lifting

Max Lift Height: 200 mm.
Lowered Fork Height: 85 mm.
Fork Dimensions: 45 mm (Thickness) x 160 mm (Width) x 1,150 mm (Length).
Overall Fork Width: Available in 550 mm (Standard/Narrow) or 685 mm (Wide).
Overall Length: Approx. 1,533 mm.
Wheelbase: 1,124 mm.

Wheels & Chassis

Wheel Material: High-grade Polyurethane (PU) — ideal for quiet operation and floor protection.
Steering Wheels: Double front wheels (often $195 \times 70$ mm or similar standard).
Load Wheels: Tandem (Double) Polyurethane fork wheels ($80 \times 70$ mm) for better stability over uneven surfaces.
Handle: Ergonomic rubber-wrapped handgrip with a 3-position control lever (Lift, Neutral, Lower).

Key Features

Heavy-Duty Pump: Equipped with a reinforced hydraulic pump designed for 3-ton loads.
Reinforced Chassis: Extra thick steel torsion-resistant construction.
Entry/Exit Rollers: Small rollers at the fork tips to help the truck enter and exit pallets smoothly, even when empty.
Powder Coated: Finished with a durable yellow and black industrial coating for corrosion resistance.
