IMOW Pallet Mover RPL301 | 3 ton
IMOW Pallet Mover RPL301 | 3 ton
General Specifications
- Model iMOW RPL301
- Drive Type Electric (Lithium-ion)
- Operator Type Pedestrian / Ride-on (Foldable Platform & Safety Arms)
- Rated Load Capacity 3,000 kg (3.0 Ton)
- Load Center Distance ($c$) 600 mm
- Service Weight ~802 kg
Description
IMOW Pallet Mover RPL301 | 3 ton
BELIALAT.COM support unit, parts, service, rental, maintenance cotract, overhaul and reconditioned IMOW Pallet Mover RPL301 | 3 ton
The iMOW RPL301 (manufactured under EP Equipment) is a heavy-duty electric ride-on/stand-on pallet mover designed for high-capacity warehouse and logistics applications.
General Specifications
| Specification | Value |
| Model | iMOW RPL301 |
| Drive Type | Electric (Lithium-ion) |
| Operator Type | Pedestrian / Ride-on (Foldable Platform & Safety Arms) |
| Rated Load Capacity | 3,000 kg (3.0 Ton) |
| Load Center Distance ($c$) | 600 mm |
| Service Weight | ~802 kg |
Dimensions & Mechanics
| Parameter | Specification |
| Lift Height (h_3) | 121 mm |
| Fork Dimensions (s/e/l) | 55 mm × 190 mm × 1,150 mm (or 1,220 mm option) |
| Length to Face of Forks (l_2) | ~824 mm |
| Overall Width (b_1) | 734 mm |
| Turning Radius (W_a) | 1,790 mm |
| Wheel Base / Setup | Strengthened loading wheel assembly |
Performance & Drive
| Metric | Specification |
| Travel Speed (Laden / Unladen) | 5.5 km/h – 6.0 km/h |
| Max. Gradeability (Laden / Unladen) | 6% / 16% |
| Steering System | Proportional Electronic Power Steering (EPS) |
| Braking System | Electromagnetic Service & Parking Brake |
| Motor Type | Vertical AC Traction Motor |
Battery & Power System
| Feature | Details |
| Battery Type | Maintenance-free Li-ion (Lithium-ion) |
| Voltage / Nominal Capacity | 24V / 205 Ah (Optional 210 Ah / 280 Ah variants) |
| Charging System | Supports fast opportunity charging (~2.5 hours full charge) |
Key Features
-
Foldable Platform & Protective Arms: Allows operators to choose between pedestrian operation or standing ride-on for long-distance transport.
-
Automatic Speed Reduction: Automatically scales down speed while executing sharp turns for stability.
-
Reinforced Chassis: Heavy-duty frame with upgraded links on the loading wheels to prevent premature wear under 3-ton loads.
