Kobelco Excavator SK330LC-10 | 34.7 ton

Description

Kobelco Excavator SK330LC-10 | 34.7 ton

BELIALAT.COM support, unit, parts, service, rental, maintenance contract, overhaul, rconditioned Kobelco Excavator SK330LC-10 | 34.7 ton

The Kobelco SK330LC-10 is a highly efficient, 34.7-ton class conventional heavy excavator designed for challenging construction and mining environments. It features an advanced arm interflow hydraulic system and a common-rail engine layout to dramatically cut fuel consumption while keeping cycle times fast.

Technical Specifications

1. Engine & Power

• Model: HINO J08ETM

• Type: 4-stroke, liquid-cooled, direct injection common-rail diesel engine with turbocharger and intercooler

• Gross Power Output: 209 kW @ 2,100 rpm (ISO 14396, without fan)

• Net Power Output: 197 kW @ 2,100 rpm (ISO 9249, with fan)

• Maximum Torque: 998 Nm @ 2,100 rpm

• Displacement: 7.684 L

2. Hydraulic System

• Pump Type: Two variable-displacement axial piston pumps + one extra gear pump

• Max. Discharge Flow: 2294 L/min, 121 L/min

• Relief Valve Settings: 34.3 MPa (Standard) / 37.8 MPa (With Power Boost engaged)

• Hydraulic Tank Oil Level: 245 L (System capacity: 410 L)

3. Machine Capacities & Performance Data

Working Range & Transport Dimensions

(Based on the standard 3.30 m HD arm and 6.50 m boom option)

• Maximum Digging Reach: 11,260 mm (11.26 m)

• Maximum Digging Depth: 7,560 mm (7.56 m)

• Maximum Vertical Wall Digging Depth: 6,480 mm (6.48 m)

• Bucket Digging Force: 222 kN (Normal) / 244 kN (With Power Boost)

• Arm Crowding Force: 163 kN (Normal) / 180 kN (With Power Boost)

Transport Dimensions

• Overall Transport Length: 11,300 mm (11.30 m)

• Overall Transport Width (with 600mm shoes): 3,190 mm (3.19 m)

• Overall Transport Height: 3,430 mm (3.43 m)

• Tail Swing Radius: 3,500 mm (3.50 m)
