Toyota Order Picker 5300-OPC30 | 3 ton

Description

Toyota Order Picker 5300-OPC30 | 3 ton

BELIALAT.COM support unit, parts, service, rental, maintenance contract, overhaul, reconditioned Toyota Order Picker 5300-OPC30 | 3 ton

The Toyota 5300-OPC30 is a light-to-medium-duty, high-level electric order picker designed primarily for narrow-aisle warehouse environments.

There is an important industry clarification regarding the capacity: while the designation OPC30 stands for a 3,000 lbs load capacity (which is approximately 1.36 tonnes or 1.5 tons at a standard 24-inch load center), the terminology in some international markets or specific fleet configurations can sometimes cause confusion with gross weight metrics. Its true maximum structural cargo capacity is 1,361 kg.

Technical Specifications

Performance & Capacity

• Load Capacity: 3,000 lbs / 1,361 kg

• Load Center: 24 inches / 600 mm

• Maximum Lift Height: Up to 241 inches / 6,121 mm (approx. 6.1 meters)

• Travel Speed (Unloaded): 6.5 mph / 10.46 km/h

• Free Lift: 22 inches / 559 mm

Dimensions & Weights

• Base Power Unit Width: 40 inches / 1,016 mm

• Head Length (Bumper to Fork Face): 74 inches / 1,880 mm

• Standard Fork Size (L x W x T): 42 x 4 x 1.5 inches (1,067 x 102 x 38 mm) (Optional 30″, 36″, and 48″ lengths available)

• Turning Radius: 72 inches / 1,829 mm

• Platform Dimensions: 39″ Width x 28.5″ Length (991 mm x 724 mm)

Electrical System & Power

• Battery Type: Lead-Acid or Lithium-ion variants

• System Voltage: 24-Volt electrical system

• Motor Control: Toyota ACR System (AC Drive and AC Lift Motors) which eliminates wearable components like carbon brushes.

Core Operational Features

• Auto-Locking Pallet Clamp: Automatically secures the pallet stringer once flush against the platform. It accommodates standard stringer thicknesses from 1.25 to 2 inches (with high-clearance options up to 5 inches).

• Auto-Steer Centering: Automatically centers the drive wheel upon machine startup, significantly reducing accidental damage to warehouse racking and product.

• Variable Lift & Lower Controls: Eliminates jerky hydraulic movements, giving operators a smooth, feathered transition for high-level spot picking.

• Intelliguide™ Wire Guidance System (Optional): Can be fitted for rail or wire-guided operation in very narrow aisles (VNA), allowing the operator to focus purely on the picking process rather than steering.

Berdasarkan spesifikasi resmi dari lini produk Toyota Material Handling (5000-Series), model Toyota Order Picker 5300-OPC30 sebenarnya memiliki kapasitas beban sebesar 3.000 lbs (atau setara dengan ±1.361 kg / 1,36 ton) pada load center 600 mm, bukan 3 ton (3.000 kg). Angka “30” pada kode OPC30 merujuk pada kapasitas 3.000 pon (pounds).

Berikut adalah detail spesifikasi unit Toyota 5300-OPC30:

1. Performa & Kapasitas

• Kapasitas Angkat Maksimum: 3.000 lbs / 1.361 kg (1,36 Ton)

• Ketinggian Angkat Platform (Lift Height): Hingga 240–241 inci (sekitar 6,1 meter)

• Ketinggian Pengambilan (Picking Height): Mencapai hingga ~7,5 meter (tergantung tinggi jangkauan operator)

• Kecepatan Jalan (Travel Speed tanpa beban): ± 10,46 km/jam

2. Sistem Listrik & Baterai

• Sistem Voltase: 24 Volt atau 36 Volt

• Tipe Motor: AC (Alternating Current) Drive & Lift Motor dengan ACR System (membuat konsumsi baterai jauh lebih hemat, bebas perawatan sikat arang/brushless, dan akselerasi lebih halus).

• Tipe Baterai: Umumnya Lead-Acid (tersedia opsi Li-Ion tergantung konfigurasi wilayah).

3. Dimensi & Roda

• Radius Putar (Turning Radius): 72 inci (1.829 mm) — dirancang sangat lincah untuk koridor gudang yang sempit (Narrow Aisle).

• Lebar Unit Keseluruhan (Overall Width): 40 – 60 inci (1.016 – 1.524 mm, tergantung opsi kaki baseleg).

• Roda Penggerak (Drive Tire): 1 buah roda Polyurethane (Ukuran 12 x 5 inci / 305 x 127 mm).

• Roda Beban (Load Tire): 2 buah roda Polyurethane (Ukuran 6 x 3.625 inci / 152 x 92 mm).

4. Fitur Utama & Keselamatan

• Auto-Locking Pallet Clamp: Penjepit palet otomatis yang mengunci berbagai ukuran ketebalan balok palet agar tidak bergeser saat naik ke ketinggian.

• Auto-Steer Centering: Ban penggerak otomatis kembali ke posisi lurus saat unit dinyalakan demi mencegah benturan di lorong rak.

• Retractable Tether & Safety Harness: Sistem tali penambat otomatis yang meminimalkan kekenduran untuk memastikan operator tetap aman di dalam kompartemen platform saat bekerja di ketinggian.

• Sistem Navigasi Lorong (Opsional): Mendukung pemasangan Intelliguide Wire Guidance System atau Rail Guidance untuk pergerakan otomatis yang aman di lorong gudang yang sangat sempit (Very Narrow Aisle / VNA).

Catatan: Jika Anda memang membutuhkan unit Order Picker atau Forklift dengan kapasitas murni 3 ton (3.000 kg), Anda kemungkinan perlu beralih ke kategori unit Counterbalance Forklift Listrik/Diesel Toyota, karena tipe High-Level Order Picker umumnya didesain dengan kapasitas maksimal di kisaran 1 hingga 1,5 ton demi menjaga stabilitas saat platform naik ke atas.
