Hyundai Forklift 18BT-9U | 1.8 ton

Description

Hyundai Forklift 18BT-9U | 1.8 ton

BELIALAT.COM support unit, parts, service, rental, maintenance cotract, overhaul and reconditioned Hyundai Forklift 18BT-9U | 1.8 ton

The Hyundai 18BT-9U is a 3-wheel electric sit-down forklift engineered for indoor material handling, tight-aisle warehouse environments, and cold storage applications. It features a 1.8-ton (1,800 kg / ~3,500 lbs) load capacity driven by a 48V dual AC motor system.

Technical Specifications Summary

1. Basic Specifications

• Rated Capacity: 1,800 kg (3,500 lbs)

• Load Center: 500 mm (24 in)

• Power Source: Electric (48V System)

• Operating Type: Sit-down / Rider

• Wheel Configuration: 3-Wheel (Front Dual Drive, Rear Single Steering Assembly)

2. Dimensions & Weights

• Overall Length (to Face of Forks): ~1,989 mm (78.3 in)

• Overall Width: 1,105 mm (43.5 in)

• Overhead Guard Height: 2,065 mm (81.3 in)

• Standard Lift Height: 3,300 mm (~131 in) (Varies by mast option)

• Free Lift (Standard): 1,205 mm (47.4 in) (Varies by duplex/triplex mast)

• Turning Radius: 1,630 mm (64.2 in)

• Fork Dimensions (Standard): 40 mm × 110 mm × 1,050 mm (1.6″ x 4.35″ x 41.3″)

• Fork Carriage: ISO Class II / Type A

• Service Weight (inc. Battery): ~3,410 kg (7,511 lbs)

3. Performance & Speed

• Travel Speed (Loaded / Unloaded): ~16 km/h (9.9 mph)

• Lifting Speed (Loaded / Unloaded): 0.40 m/s / 0.55 m/s

• Lowering Speed (Loaded): 0.55 m/s

• Max Gradeability (Loaded): 27.5%

• Brake Type: Wet Disc Brakes (Hydraulic)

4. Motor, Powertrain & Electrical

• Drive Motor: Dual ZF-Schabmueller Brushless AC Motors (2× 4.5 kW to 2× 12.9 kW max burst)

• Hoist/Lift Motor: AC 14.9 kW (15.1 hp)

• Control System: ZAPI ACE Controller (Dual MiCOM, IP65-rated)

• Battery Options:

  • Lead-Acid: 48V / 510 Ah–585 Ah

  • Li-Ion Ready: 100% factory Lithium-Ion compatible with opportunity fast-charging

5. Operating Features & Safety Systems

• Selectable Performance Modes: High, Normal, and Economy modes for balancing speed vs. battery autonomy.

• Electronic Power Steering (EPS): Speed-adaptive steering with force feedback.

• Operator Presence Sensing System (OPSS): Prevents lift/drive functions if the operator leaves the seat.

• Cornering & Hill Control: Automatic Curve Speed Control and Anti-Rollback (Hill Assist Control).

• Display & Diagnostics: Onboard LCD cluster with real-time load weight indicator, battery status, and diagnostic maintenance tracking.
